MT8071IP replace MT8070iH5 weinview HMI touch screen 7" Ethernet new in

MT (iP) series is weinview compactman-machine interface, using Cortex A8 600MHz CPU processor design. MT (iP)series including: 4.3 (MT6051iP), 7 (MT8071iP / MT6071iP) and 10.1 (MT6103iP)and other three dimensions, four models, to meet your various needs ofdifferent applications.

The built-in high speed Cortex A8 processorand has high chroma up to 16 million color display, to provide the best resultsfor the user experience. Equipped with EasyBuilder Pro (V5.05.01 or above)software, to provide a more sophisticated picture design and superior featuresand features, the most consistent with the user needs.

In addition, MT (iP) series of client Microusing USB USB connector, more durable than the USB Mini connector, and Androidsmart phone USB connection line can be directly used. USB Micro connector cansignificantly reduce the damage from the vertical or horizontal pressure, itsplug and plug durability is better than USB mini (USB Micro: the number of plugup to more than 10 thousand times; USB Mini: more than 5000 times the number ofplug).

Product features

Efficient energy

Equipped with A8 600MHz CPU 128MB, Flash128MB, RAM Cortex.

High awareness

16 million color display, high chroma.

Full compatibility

EasyBuilder engineering software, theopening size and connectors (except client USB), fully compatible with the MT(iH) series.

Strong connectivity

Support more than 300 kinds ofcommunication drivers, can be connected to a variety of different manufacturersof PLC and controller.

Four models, three dimensions of choice

- 10.1 - MT6103iP

Configuration 10.1 "high resolutionLCD (1024x600 pixels, 16.2M colors) and have a wider viewing angle

- 7 - MT6071iP / MT8071iP

- 4.3 - MT6051iP

*MT6xxxiP for no Ethernet models.

*MT8xxxiP with an Ethernet model.

Note: MT6103iP COM3 RS-485 can choose 2W orRS-232.

However, when COM3 selects RS-232, COM1 RS-232can only use Tx & Rx (no RTS/CTS).
